α(Alpha)-μ–OFC Conductor is the fine μ–OFC conductor wire strands treated with the α(Alpha) process.
Cable Specifications:
• α (Alpha) μ -OFC conductor : 7 bundles 35 strands ( 7 búi x 35 sơi )
• 0.16mm diameter 10AWG (5.0sq.mm)
• Insulation: Polyethylene (Red/Natural /Yellow) 5.2mm diameter
• Inner Sheath: Audio grade flexible PVC (Black) incorporating carbon damping particles, 12.0mm diameter
• Shield: 9 x 24 strands of 0.12mm stranded-braid α (Alpha) conductor
• Sheath: Flexible PVC (Dark Blue) approx. 15.5mm diameter.
